There are 10 groups of standard procedures and 10 groups of teaching procedures. Each group of teaching procedures can be written up to 100 steps, and can be written at the same time as needed
4 steps. With self-test function, it can check the input and output signals at any time, and record the top 20 groups of fault data for reference
Maintenance reference. The traverse speed can be adjusted according to the percentage.
With 8 groups of output and 5 groups of input points, it can be connected with other peripheral automation equipment
1) In mold traverse function: when the inverted hook die is taken out, the function of in mold traverse can be applied to simplify the fixture design
According to the production cost, the difficulty of removal is reduced.
2) Multi point and diversified placement function of finished products: it can be placed in 9 cycles, and can be divided into two zones, with a total of 18 points, and then set the lead
It can also be placed in two rows and two zones with 36 points. It can also be placed in circulation with fixed distance
If the setting mode is fixed, 99 points or 198 points can be set outside the mold.
3) Connection and application of peripheral devices: conveyor belt, air jet device, cutting device, electric eye detection and secondary peripheral devices can be connected
Equipment to form the automation system after removal.
4) Quality inspection function:
① When the ejection machine sends out the signal of defective product, the finished product can be placed in the defective product area.
② Sampling function: after several mold times can be set, a sample can be selected and placed in the quality inspection area to facilitate the application of quality inspection.
③ Test product is not included in the counting function: you can set several times not included in the counting function.
④ Production quantity setting: can be set
After the production module is set, the manipulator will stop operation automatically.
